Cybrid

180W LED Beam

  • One 6-in Line Prism.
  • Fun 3D Effects.
  • 8-Facet Prism.
  • Stunning Water Effect.


Rasha's family of moving heads introduces Cybrid, a sophisticated and compact LED moving head luminaire.

Its unique beam effect engine and carefully calibrated LED emitter transforms the light output into a great dynamic ray of true color mid-air effect, beautiful gobos, prism and smooth color.

Cybrid features a 180W white LED light engine, perfectly calibrated with a new optical lens, directional & bi-directional 1x dichroic color wheel with 8 colors, 1x fixed gobo wheel with 8 gobos, 1x rotating glass gobo wheel with 7 rotatable and replaceable gobos. Cybrid produces a uniform beam, high light intensity, smooth colors, and prism effects with micro-beams. These effects are frequently used in small to big event production, night clubs, venues, theaters, houses of worship, and studios. Its light output & per watt lumen ratio is amazing and comparable to a sharp 5R beam.

With its low energy consumption, light weight design, and its 50,000 + hr life, makes this fixture a must have.

PHYSICAL

Weight 27.3 lb (12.4KG)
Dimensions 13 x 9 x 17.5 in

DYNAMIC EFFECTS

Color Mixing Independently Variable, Full & Half Color
Color Wheel 8 -Color's + White; Rotation with variable direction and speed
Fixed Gobo Wheel 8 Gobos Wheel & Shake
Rotating Gobo 7 Rotating Gobo Wheels
Prism 8 Facet Prism, 6-In Line Bi-Directionally Rotable at Variable Speeds & Frost Filter
Mechanical Dimmer 0-100%
Shutter High Speed Strobe Effect with 1-25 Flashers Per Second
Zoom Motorized Linear Zoom
Pan / Tilt 540°/246°

OPTICS

Type 180W LED Light Engine
LED's Beam Angle 8° Minimum
CRI ( Color Rendering Index ) 95
Minimum LED Lifetime 50,000 Hours ( to>70% Lumen Output)*
*Manufacturer's Figure Obtained Under Manufacturer's Test Conditions.

CONTROL AND PROGRAMMING

Control Options DMX, Sound Active, Auto, Static Mode & Wireless (Optional)
DMX Channels 16 DMX Channels
Stand-Alone Trigger Options Music Trig
Settings, Addressing & Programming LED Screen With Menu Buttons
Sound Activation Microphone
DMX Compliance USITT DMX512/1990/ DMX 512 Universal
Wireless DMX Transmitter Compliance Universal DMX 512-2.4GHz with 7 Group

CONSTRUCTION

Color(s) Black/White
Housing UV-Resistant Fiber- Reinforced Composite/ Thermoplastic
Reflector High-Profile Optical Lens
Protection Rating IP 20

ELECTRICAL

AC Power Input AC90V-240V / 50/60Hz
AC Power In-Port PowerCon Female (Blue) Type-A
AC Power Out-Port PowerCon Female (White) Type-A
AC Power Throughput 180W
Fuse T 5.0A

APPROVALS

EU Safety/EU EMC EN 60598-2-17/EN 55015, EN 55103-1, EN 61547
US Safety/ US EMC UL 1573/ FCC Part 15 Class A

INSTALLATION

Mounting Points Omega Bracket, Surface or Truss Mount, Free Standing
Location Indoor Use Only
Orientation Any

THERMAL

Maximum Ambient Temperature (Ta max.) 40° C (104° F)
Minimum Ambient Temperature (Ta min) 0° C (32° F)
Surface Temperature 85° C (185° F)

INCLUDED ITEMS

DMX Input Cable 5ft with 3 Pin or 5 Pin P/N 890507
Power Input Cable 5ft with Neutrik Blue Connector P/N 890507
Omega Clamp Brackets P/N 890505

ACCESORIES

Wireless DMX Transmitter* P/N 920101
G-Clamp* P/N 890107
Half-Coupler Clamp* P/N 890108
Quick Trigger Clamp* P/N 890109
Safety Wire* P/N 890110
Road Case 2 in 1* P/N 901108 | P/N 901109
*All Accessories Sold Separately

ORDERING INFORMATION

Cyrbid in Cardboard Box P/N 816180
Cybrid in Road Case 2 in 1 P/N 816182
