Rasha Professional

    Photon Hybrid

    UPC: 766429777663

    Product Code: Photon Hybrid

    All In One Hybrid Moving Head Light

    • CMY color mixing system
    • 7 dichroic filter color wheel with CTO, CT
    • 8 rotating Interchangeable Glass gobo
    • 9 Static stamp gobo
    • Animation wheel
    • Motorized Zoom  6°- 42° with Auto Focus
    • High-Speed Iris Range: 5%-100%
    • 5-Facet Circular Prism

    Play Video
    Photon Hybrid
    Photon Hybrid
    Photon Hybrid
    Photon Hybrid
    Photon Hybrid
    Photon Hybrid
    Photon Hybrid

    Photon Hybrid

    Product Code: Photon Hybrid

    All In One Hybrid Moving Head Light

    • CMY color mixing system
    • 7 dichroic filter color wheel with CTO, CT
    • 8 rotating Interchangeable Glass gobo
    • 9 Static stamp gobo
    • Animation wheel
    • Motorized Zoom  6°- 42° with Auto Focus
    • High-Speed Iris Range: 5%-100%
    • 5-Facet Circular Prism

    $1,765.00

    Total Price: $1,765.00 Reward Points:

    – +
    • Fast
      Shipping
    • Free Tech
      Support
    • Free 2-year
      Warranty
    Availability: Photon HybridIn-Stock

    Photon HybridMonthly Payments. No Hidden ChargesKnow More
    Buy from Reseller

    BUY FROM LOCAL RESELLER

    Check Availability At

    Our Expert Sales Team ready to help you!

    (951) 394-8480

    Photon Hybrid Email Us

    Introducing Photon HybridTM moving head light, the ultimate all-in-one luminaire that combines Spot, Beam, and Wash capabilities into a compact and powerful package. Equipped with a high-power 6500K LED light engine, Photon HybridTM moving head light delivers an impressive output of 11000 lumens, ensuring stunning lighting displays for any event or venue.
    Photon HybridTM moving head light offers an array of cutting-edge features, including a 7 dichroic color filter system with CMY + CTO color mixing, providing a versatile range of colors and shades. The luminaire also boasts a variable color temperature, adjustable from 2700K to 6500K, allowing for precise and dynamic color control.

    With a motorized zoom ranging from 6° to 42°, Photon HybridTM offers convenient auto-focus functionality, ensuring sharp and accurate lighting projections. Its comprehensive gobo options include 8 rotating interchangeable glass gobos and 9 static stamp gobos, providing endless creative possibilities for captivating lighting displays. Additionally, an animation wheel delivers a special dynamic water effect, adding a touch of magic to any lighting show.

    Photon HybridTM moving head light is equipped with advanced protocol support, including DMX, RDM (Remote Device Management), Art-NET, and SACN, ensuring seamless integration and control. It features 5-pin XLR and Neutrik TRUE1 power in/out connections, ensuring reliable and secure power connections for your lighting setup.

    A full-color 180° reversible LCD menu display with battery backup allows for effortless navigation and setup adjustments. Photon HybridTM is powered by a multi-voltage universal auto- switching power supply (100-240V), offering worldwide compatibility and convenience. The luminaire comes with a comprehensive 2-year ultimate warranty, ensuring peace of mind and reliability.
    In conclusion, Photon HybridTM moving head light sets a new standard for all-in-one luminaires, delivering exceptional performance, versatility, and reliability for any event or venue. With its advanced features, powerful output, and comprehensive warranty, Photon HybridTM is the ideal choice for lighting professionals seeking to create captivating and memorable lighting displays.
    Highlights :
    DMX channels: 25/36 Channel Mode
    Prism:1 bidirectional 5-facet rotating prism, prism can be positioned
    Focus: Motorized focus, auto focus
    5-100% electronic Iris
    Shutter: electronic, variable from 1-25HZ or random
    Dimming: 0-100% linear dimming
    Frost: heavy frost
    Zoom: 6°- 42 °Linear zoom
    Animation Wheel: special dynamic water effect
    Protocal: DMX 512, RDM, Artnet
    Advanced volatilization liquid cooling system

    In the Box

    • 1 x User Manual
    • 2 x Omega brackets with 1/4 turn fasteners for rigging clamp attachment
    Technical Specification

    PHYSICAL

    Weight26.1kg (57.6 lbs.)
    Dimensions (LxWxH)10.5 x 15.4 x 28.9 in (267 x 393 x 736 mm)

    DYNAMIC EFFECTS

    Electronic shutter effectStrobe effect, pulse effects, instant open and blackout
    Electronic dimming0 - 100%, four dimming curve options
    Color mixingCMY, CTO, CT independently variable 0-100%
    Color wheel7 color filters plus open
    Gobo animationAnimation wheel, indexing, continuous rotation with variable speed and direction
    Rotating gobo wheel7 gobos plus open, wheel rotation, gobo rotation, indexing and shake
    Static gobo wheel8 gobos plus open, wheel indexing, rotation and shake
    Iris0-100%
    ZoomMotorized
    Color temperature controlVariable 2700-6500K
    Prism1 rotating/indexing prisms (4-facet circular)
    FrostHeavy frost effect
    Pan540°, coarse & fine control and speed
    Tilt260°, coarse & fine control and speed
    FocusMotorized

    OPTICS

    Front lens diameter120 mm (4.75 in.)
    Zoom range6° - 42° (1:7)
    FocusAuto Focus
    Light source460 W LED engine
    Minimum LED lifetimeMinimum LED lifetime

    CONTROL AND PROGRAMMING

    Control optionsDMX
    16-bit control Dimming, CMY, CTO, CT, Zoom, Focus, Pan and Tilt
    Setting and addressingControl panel with backlit LCD display
    DMX channels25/36
    DMX complianceUSITT DMX512/1990
    RDM complianceANSI/ESTA E1.20

    CONSTRUCTION

    HousingHigh-impact flame-retardant thermoplastic
    ColorBlack
    Protection ratingIP20

    INCLUDED ITEMS

    Two omega brackets with 1/4 turn fasteners for rigging clamp attachment 2 x P/ N 91602001
    Power cable Edison to True1

    INSTALLATION

    Mounting points2 pairs of 1/4-turn points for 106 mm (4.17 in.) center-to-center omega brackets
    LocationDry location only, must be fastened to surface or structure
    OrientationAny
    Minimum distance to combustible materials0.2 m (8 in.)
    Minimum distance to illuminated surfaces 2.0 m (6.6 ft.)
    DMX and RDM data in/out3 & 5-pin locking XLR
    AC mains power inputNeutrik TRUE1 socket, accepts TRUE1 NAC3FX-W (TOP) connector
    AC mains power throughput Neutrik TRUE1 socket, accepts TRUE1 NAC3MX-W (TOP) connector

    THERMAL

    CoolingForced air (temperature-regulated, low noise)
    Maximum ambient temperature (Ta max.)40° C (104° F)
    Minimum ambient temperature (Ta min.)5° C (41° F)
    Maximum surface temperature, steady state, at 40° C ambient75° C (167° F)
    Maximum total heat dissipation, calculated, +/- 10%2920 BTU/hr.

    CONNECTORS

    DMX and RDM data in/outLocking 3 & 5-pin XLR

    GOBOS

    Maximum image diameter19 mm (0.75 in.)
    Gobo materialBorofloat 33
    External diameter23.0 mm +0 / -0.2 mm (0.906 in. +0 / -0.008 in.)
    Maximum gobo thickness1.1 mm (0.04 in.)
    CoatingHeavy matted aluminum

    TYPICAL POWER AND CURRENT

    120 V, 60 Hz4.5 A, 550W, PF 0.994
    230 V, 50 Hz2.4A, 550 W, PF 0.967
    Figures are typical, not maximum. Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%. PF = power factor

    CERTIFICATIONS / QUALIFICATIONS

    EU safetyEN 60598-2-17 (EN 60598-1), EN 62471, EN62493
    EU EMCEN 55015, EN 55032, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61547
    US safetyUL 1573
    US EMCFCC Part 15 Class B
    Canadian safetyCSA C22.2 No. 166
    Canadian EMCICES-3 (B) / NMB-3 (B); ICES-5 (B) / NMB-5 (B)
    Australia/NZRCM
    Global CB Certification/IECEEIEC 60598-2-17 (IEC 60598-1)

    Note: - Please note that product specifications may change without prior notice*

    Downloads
      Version Language Size Update Date
    Manuals
    Photon Hybrid Manual
    en version B, updated: Aug 15, 2021
    		3  en  1.30 MB 10th Jun 2024
    Profiles
    Photon Hybrid SSL2
    en version B, updated: Aug 15, 2021
    		1.5  en  56.84 kB 28th May 2019
    Avolite D4 Profile
    en version B, updated: Aug 15, 2021
    		1  en  13.77 kB 24th Oct 2022
    Avolite R20 Profile
    en version B, updated: Aug 15, 2021
    		1  en  7.91 MB 24th Oct 2022
    DMX Charts
    Photon Hybrid DMX chart
    en version B, updated: Aug 15, 2021
    		1  en  827.58 kB 13th Jul 2023
