The "On Stage" P2.5 Indoor/Outdoor LED Wall Panel is an advanced and versatile solution designed for both indoor and outdoor video production. This high-performance panel combines cutting-edge technology, superior image quality, and durability to deliver stunning visual experiences in any setting.
Featuring a pixel pitch of 2.5mm, this LED wall panel ensures exceptional image clarity and detail, even at close viewing distances. The high-resolution display allows for sharp and vibrant visuals, making it perfect for applications such as concerts, sports events, trade shows, and other indoor and outdoor events where visual impact is crucial. The "On Stage" P2.5 panel is engineered to provide superior image quality, rendering every detail with precision. It produces vibrant colors, remarkable clarity, and lifelike imagery, ensuring captivating visuals that engage the audience. This level of image quality is essential for maintaining the integrity of creative designs, branding, and visual storytelling.
With its versatile design, the "On Stage" P2.5 panel can be used both indoors and outdoors. It is built to withstand various environmental conditions, making it suitable for outdoor applications. Its rugged construction and weather-resistant properties ensure reliable performance, even in challenging outdoor settings. This durability allows for worry-free usage, enabling seamless productions without compromising on quality. The panel is designed for ease of installation and flexibility. Its lightweight and slim profile makes it easy to handle and mount on various structures such as truss systems or rigging, allowing for flexible stage design and setup. Whether it's an indoor concert or an outdoor event, the panel seamlessly integrates into the overall aesthetics, providing a clean and professional look.
Features:
Module | 96 pixel * 96 pixel/ Module |
Module Size | 250MM * 250MM * 5MM |
Cabinet Resolution Ratio | 192 Pixel *192 Pixel |
Module Group | 2 X 2 |
Tile size | 500MM * 500MM * 80MM |
Cabinet Weight per tile | 7.05Kg, 15.5lb /Tile |
Pixel Pitch | 2.5mm |
Pixel per tile | 40000 Pixel/tile(200(H)*200(V) |
Processing | Red, Green, Blue ≥12bit |
Drive Mode | Constant current |
3D | 3D Supported |
Refresh rate | ≥3840Hz |
Colors | 281 trillion |
Color Temperature | 4000K~9500K, Adjustable |
Brightness | 1000 nits - Adjustable |
Dimming | 0-100% |
Effective sight distance | ≤0.1mm |
Brightness uniformity | ≥98% |
Ip rating | IP31 |
Control | Nova Star |
Operating System | Windows / Mac OS |
Color(s) | Black |
Cabinet Material | Magnetic Die-casted Aluminum |
Corner Protection | Built in corner guard |
Serviceability | Front service |
Modules | Magnetic modules |
Modules Replacement | Manually push out extraction |
Operational Power Voltage | 100-240V / 50-60Hz |
Max Power | ≤78Watt/Tile, 0.70A @124V |
Mean Power | 312W/m2~315W/m² @ 124V |
Working Times | ≥7×24hrs |
LED Life LED | 100000 hours |
Operational Temperature | -10℃ to 60℃ / -14F to 140F |
Operational Humidity | 10% to 90%RH |
Mean Fault Free | ≥10000 hours |
Lamp | Kinglight |
IC | FM6353/ICN2153 |
Receive card | Nova star A5Splus |
Flight case | 8 in 1 |
Note: - Please note that product specifications may change without prior notice*
