UPC: 766429779551
Product Code: RP-CIP-BLK
In-Stock
Monthly Payments. No Hidden ChargesKnow MoreCheck Availability At
The Core IP is built for durability and versatility, offering high-performance lighting for both indoor and outdoor applications. Its IP65-rated design ensures reliable operation in any environment, while four RGBWA+UV LEDs project a combined 1500 lux at 5 meters, delivering vibrant, high-output illumination. With adjustable color temperature, built-in presets, and PWM control, it provides seamless customization for any event.
Featuring a silent, fanless design, the Core IP operates noise-free, making it ideal for professional settings. It supports wireless DMX, CRMX, IR remote, and app control for effortless operation. A built-in carrying handle ensures easy transport, and an M10 mounting hole allows secure rigging. With up to 20 hours of battery life, the Core IP is a dependable lighting solution for any production or event.
| Dimensions (LxWxH) | 5.4 x 5.4 x 6.25 in (138 x 138 x 158.75 mm) |
| Weight | 6.3 Lbs (2.8kg) |
| Dimming | 8 Bit |
| Shutter/Strobe | Electronic, 1 to 25 Hz |
| Built-in Programs | (32) Built-in Static Colors Presets |
| (23) Adjustable Color Temperature Presets (2,000K - 10,000K) | |
| (1) Auto-Run Program with adjustable speed | |
| (4) Sound Programs | |
| Dimmer Curves | 4 (Linear, S Law, Inv S Law, S-Curve) |
| Light Source | (4) 18W Hex Color (RGBWA+UV) LED , 50,000 hours life expectancy |
| Color Temperature @ Full | 10,000K |
| Color Temperature Range | 2,000K - 10,000K |
| Beam Angle | 25° |
| Illuminance | 1500 Lux @ 5m |
| Selectable PWM | 600 Hz, 1200 Hz, 2000 Hz, 4000Hz, 12k Hz, 25k Hz |
| Control Options | Wireless DMX, Manual, Auto, IR Remote, App Control |
| DMX Modes | 2Ch, 6CH, 8CH, 11Ch |
| Wireless Operation Modes | Transmit, Receive |
| Wireless Operating Frequency | 2.4 GHz |
| Housing | Aluminum die-cast |
| Fixture Color | Black or White |
| Menu Display | LCD Menu Display |
| Battery Life Indicator on display | Yes |
| Mounting Hole | M10 |
| Input Voltage To Power Supply | 110 to 240 VAC, 50/60Hz (auto-ranging) |
| Input Voltage To Fixture | 12.6V DC |
| Single Unit Charging | 112 Watts, 1 Amp @ 120V, 60Hz |
| 112 Watts, .5 Amps @ 208V, 60Hz | |
| Case Charging (8 Units) | 900 Watts, 7.4 Amps @ 120V, 60Hz |
| 900 Watts, 4.3 Amps @ 208V, 60Hz | |
| Battery Life | All On - 8 hours |
| Single Color - 20 hours | |
| Recharge Time | 5 hours |
| Run Times (Adjustable) | 2, 4, 6, 8 Hrs |
| Fixture | (1) Core IP |
| Power Supply | (1) AC to DC 12.6v Power Supply IP20 |
| Remote | (1) IR Remote |
| Cases | Flight Case for 8 Units with integrated charging |
| Clamps | https://www.rashaprofessional.com/clamps |
| Cardboard Box | |
| Power Cables | https://www.rashaprofessional.com/cables |
| Safety Cables | https://www.rashaprofessional.com/clamps/safety-chains |
| Core IP Charging Road Case (Capacity: Holds 8 Lights and Accessories) | RP-CIP-RC |
| Core IP Fixture (Black) | RP-CIP-BLK |
| Core IP Fixture (White) | RP-CIP-WHT |
| Power Connections | (1) IP65 12V DC Coaxial Power Connector Input |
| Rigging Points | (1) M10 threaded hole (max depth 13 mm), |
| Recommended bolt for clamp Attachment | M10 x 10 mm. |
| Safety Cable Points | Optional—handle can accommodated as a safety point if needed. |
| Install Orientation | Any |
| Cooling System | Passive cooling via die-cast aluminum body. |
| Operating Temperature | -30°F to 185°F ( -30°C to 85°C) |
| IP Rating | IP65 |
Note: - Please note that product specifications may change without prior notice*
Manuals | ||||
 Core IP Manual  version B, updated: Aug 15, 2021 | ||||
Profiles | ||||
 Core IP.ssl2  version B, updated: Aug 15, 2021 | ||||
 GDTF  version B, updated: Aug 15, 2021 | ||||
 GrandMA 2  version B, updated: Aug 15, 2021 | ||||
